Steel Brake Line Union, 3/16″ (3/8-24 Bubble)

3/16″ (3/8-24 Bubble) Steel Brake Line Union

Description

Unions are used to join two brake, fuel, or transmission lines together. This may be needed, for example, in long runs from the dual master cylinder to the rear axle. Match the thread and flare type to the lines being connected. It is important that both flare type and thread match for a leak-proof connection. Use for joining 3/16″ British brake lines.

Specifications

Material: Steel
SAE or Metric: SAE
Thread Diameter: 3/8 – 24 in
Tube Diameter: 3/16 in

Interchanges

Fairview Fittings: 142BR-3
Raybestos Brake: WUB594
Edelmann: 275300
Papco: PC1190
FMSI Universal: 3047
NAPA Brakes: 641-5015
CARQUEST: 275300
Weatherhead: 7940
Coronet: 309-6
Dynamic: 1594
